耐高溫電感式傳感器
最高工作溫度為230°C
不繡鋼外殼1.4305 St Stl
不同的結構和尺寸，可靠的產品質量，溫漂性能穩定
行業應用：汽車行業 / 包裝行業 / 智能倉儲 / 冶金工業 / 石油化工 / 印刷行業 / 機床行業 / 紡織行業 / 食品行業 / 工廠自動化
電感式接近傳感器
基本參數
- M8
- M12
- M18
- M30
| 型號 | 照片 | 規格 | 感應距離 | 開關頻率 | 安裝方式 | 輸出信號 | 產品長度 | 連接方式 |
|---|---|---|---|---|---|---|---|---|
| POH-M0802N1-DF3-140 |  |
M8 | 2mm | Flush 齊平 | NPN.NO | 45mm | Cable,2m,3-wire | |
| POH-M0802N2-DF3-140 | |
M8 | 2mm | Flush 齊平 | NPN.NC | 45mm | Cable,2m,3-wire | |
| POH-M0802P1-DF3-140 | |
M8 | 2mm | Flush 齊平 | PNP.NO | 45mm | Cable,2m,3-wire | |
| POH-M0802P2-DF3-140 | |
M8 | 2mm | Flush 齊平 | PNP.NC | 45mm | Cable,2m,3-wire | |
| PHH-M0804N1-DF3-140 |  |
M8 | 4mm | Non-flush 非齊平 | NPN.NO | 45mm | Cable,2m,3-wire | |
| PHH-M0804N2-DF3-140 | |
M8 | 4mm | Non-flush 非齊平 | NPN.NC | 45mm | Cable,2m,3-wire | |
| PHH-M0804P1-DF3-140 | |
M8 | 4mm | Non-flush 非齊平 | PNP.NO | 45mm | Cable,2m,3-wire | |
| PHH-M0804P2-DF3-140 | |
M8 | 4mm | Non-flush 非齊平 | PNP.NC | 45mm | Cable,2m,3-wire |
| 型號 | 照片 | 規格 | 感應距離 | 開關頻率 | 安裝方式 | 輸出信號 | 產品長度 | 連接方式 |
|---|---|---|---|---|---|---|---|---|
| POH-M1202N1-DF3-120 |  |
M12 | 2mm | Flush 齊平 | NPN.NO | 50mm | Cable,2m,3-wire | |
| POH-M1202N2-DF3-120 | |
M12 | 2mm | Flush 齊平 | NPN.NC | 50mm | Cable,2m,3-wire | |
| POH-M1202P1-DF3-120 | |
M12 | 2mm | Flush 齊平 | PNP.NO | 50mm | Cable,2m,3-wire | |
| POH-M1202P2-DF3-120 | |
M12 | 2mm | Flush 齊平 | PNP.NC | 50mm | Cable,2m,3-wire | |
| PHH-M1204N1-DF3-120 |  |
M12 | 4mm | Non-flush 非齊平 | NPN.NO | 50mm | Cable,2m,3-wire | |
| PHH-M1204N2-DF3-120 | |
M12 | 4mm | Non-flush 非齊平 | NPN.NC | 50mm | Cable,2m,3-wire | |
| PHH-M1204P1-DF3-120 | |
M12 | 4mm | Non-flush 非齊平 | PNP.NO | 50mm | Cable,2m,3-wire | |
| PHH-M1204P2-DF3-120 | |
M12 | 4mm | Non-flush 非齊平 | PNP.NC | 50mm | Cable,2m,3-wire | |
| POH-M1203N1-DF3-150 | |
M12 | 3mm | Flush 齊平 | NPN.NO | 50mm | Cable,2m,3-wire | |
| POH-M1203N2-DF3-150 | |
M12 | 3mm | Flush 齊平 | NPN.NC | 50mm | Cable,2m,3-wire | |
| POH-M1203P1-DF3-150 | |
M12 | 3mm | Flush 齊平 | PNP.NO | 50mm | Cable,2m,3-wire | |
| POH-M1203P2-DF3-150 | |
M12 | 3mm | Flush 齊平 | PNP.NC | 50mm | Cable,2m,3-wire | |
| PHH-M1204N1-DF3-150 | |
M12 | 4mm | Non-flush 非齊平 | NPN.NO | 50mm | Cable,2m,3-wire | |
| PHH-M1204N2-DF3-150 | |
M12 | 4mm | Non-flush 非齊平 | NPN.NC | 50mm | Cable,2m,3-wire | |
| PHH-M1204P1-DF3-150 | |
M12 | 4mm | Non-flush 非齊平 | PNP.NO | 50mm | Cable,2m,3-wire | |
| PHH-M1204P2-DF3-150 | |
M12 | 4mm | Non-flush 非齊平 | PNP.NC | 50mm | Cable,2m,3-wire | |
| POH-M1202N1-DF3-220 | |
M12 | 2mm | Flush 齊平 | NPN.NO | 50mm | Cable,2m,3-wire | |
| POH-M1202N2-DF3-220 | |
M12 | 2mm | Flush 齊平 | NPN.NC | 50mm | Cable,2m,3-wire | |
| POH-M1202P1-DF3-220 | |
M12 | 2mm | Flush 齊平 | PNP.NO | 50mm | Cable,2m,3-wire | |
| POH-M1202P2-DF3-220 | |
M12 | 2mm | Flush 齊平 | PNP.NC | 50mm | Cable,2m,3-wire |
| 型號 | 照片 | 規格 | 感應距離 | 開關頻率 | 安裝方式 | 輸出信號 | 產品長度 | 連接方式 |
|---|---|---|---|---|---|---|---|---|
| POH-M1805N1-DF3-120 |  |
M18 | 5mm | Flush 齊平 | NPN.NO | 55mm | Cable,2m,3-wire | |
| POH-M1805N2-DF3-120 | |
M18 | 5mm | Flush 齊平 | NPN.NC | 55mm | Cable,2m,3-wire | |
| POH-M1805P1-DF3-120 | |
M18 | 5mm | Flush 齊平 | PNP.NO | 55mm | Cable,2m,3-wire | |
| POH-M1805P2-DF3-120 | |
M18 | 5mm | Flush 齊平 | PNP.NC | 55mm | Cable,2m,3-wire | |
| PHH-M1808N1-DF3-120 |  |
M18 | 8mm | Non-flush 非齊平 | NPN.NO | 55mm | Cable,2m,3-wire | |
| PHH-M1808N2-DF3-120 | |
M18 | 8mm | Non-flush 非齊平 | NPN.NC | 55mm | Cable,2m,3-wire | |
| PHH-M1808P1-DF3-120 | |
M18 | 8mm | Non-flush 非齊平 | PNP.NO | 55mm | Cable,2m,3-wire | |
| PHH-M1808P2-DF3-120 | |
M18 | 8mm | Non-flush 非齊平 | PNP.NC | 55mm | Cable,2m,3-wire | |
| POH-M1805N1-DF3-150 | |
M18 | 5mm | Flush 齊平 | NPN.NO | 55mm | Cable,2m,3-wire | |
| POH-M1805N2-DF3-150 | |
M18 | 5mm | Flush 齊平 | NPN.NC | 55mm | Cable,2m,3-wire | |
| POH-M1805P1-DF3-150 | |
M18 | 5mm | Flush 齊平 | PNP.NO | 55mm | Cable,2m,3-wire | |
| POH-M1805P2-DF3-150 | |
M18 | 5mm | Flush 齊平 | PNP.NC | 55mm | Cable,2m,3-wire | |
| PHH-M1808N1-DF3-150 | |
M18 | 8mm | Non-flush 非齊平 | NPN.NO | 55mm | Cable,2m,3-wire | |
| PHH-M1808N2-DF3-150 | |
M18 | 8mm | Non-flush 非齊平 | NPN.NC | 55mm | Cable,2m,3-wire | |
| PHH-M1808P1-DF3-150 | |
M18 | 8mm | Non-flush 非齊平 | PNP.NO | 55mm | Cable,2m,3-wire | |
| PHH-M1808P2-DF3-150 | |
M18 | 8mm | Non-flush 非齊平 | PNP.NC | 55mm | Cable,2m,3-wire | |
| POH-M1805N1-DF3-230 | |
M18 | 5mm | Flush 齊平 | NPN.NO | 55mm | Cable,2m,3-wire | |
| POH-M1805N2-DF3-230 | |
M18 | 5mm | Flush 齊平 | NPN.NC | 55mm | Cable,2m,3-wire | |
| POH-M1805P1-DF3-230 | |
M18 | 5mm | Flush 齊平 | PNP.NO | 55mm | Cable,2m,3-wire | |
| POH-M1805P2-DF3-230 | |
M18 | 5mm | Flush 齊平 | PNP.NC | 55mm | Cable,2m,3-wire | |
| PHH-M1808N1-DF3-230 | |
M18 | 8mm | Non-flush 非齊平 | NPN.NO | 55mm | Cable,2m,3-wire | |
| PHH-M1808N2-DF3-230 | |
M18 | 8mm | Non-flush 非齊平 | NPN.NC | 55mm | Cable,2m,3-wire | |
| PHH-M1808P1-DF3-230 | |
M18 | 8mm | Non-flush 非齊平 | PNP.NO | 55mm | Cable,2m,3-wire | |
| PHH-M1808P2-DF3-230 | |
M18 | 8mm | Non-flush 非齊平 | PNP.NC | 55mm | Cable,2m,3-wire |
| 型號 | 照片 | 規格 | 感應距離 | 開關頻率 | 安裝方式 | 輸出信號 | 產品長度 | 連接方式 |
|---|---|---|---|---|---|---|---|---|
| POH-M3010N1-DF3-180 |  |
M30 | 10mm | Flush 齊平 | NPN.NO | 55mm | Cable,2m,3-wire | |
| POH-M3010N2-DF3-180 | |
M30 | 10mm | Flush 齊平 | NPN.NC | 55mm | Cable,2m,3-wire | |
| POH-M3010P1-DF3-180 | |
M30 | 10mm | Flush 齊平 | PNP.NO | 55mm | Cable,2m,3-wire | |
| POH-M3010P2-DF3-180 | |
M30 | 10mm | Flush 齊平 | PNP.NC | 55mm | Cable,2m,3-wire | |
| PHH-M3015N1-DF3-180 |  |
M30 | 15mm | Non-flush 非齊平 | NPN.NO | 55mm | Cable,2m,3-wire | |
| PHH-M3015N2-DF3-18 | |
M30 | 15mm | Non-flush 非齊平 | NPN.NC | 55mm | Cable,2m,3-wire | |
| PHH-M3015P1-DF3-180 | |
M30 | 15mm | Non-flush 非齊平 | PNP.NO | 55mm | Cable,2m,3-wire | |
| PHH-M3015P2-DF3-180 | |
M30 | 15mm | Non-flush 非齊平 | PNP.NC | 55mm | Cable,2m,3-wire | |
| POH-M3010N1-DF3-230 | |
M30 | 10mm | Flush 齊平 | NPN.NO | 55mm | Cable,2m,3-wire | |
| POH-M3010N2-DF3-230 | |
M30 | 10mm | Flush 齊平 | NPN.NC | 55mm | Cable,2m,3-wire | |
| POH-M3010P1-DF3-230 | |
M30 | 10mm | Flush 齊平 | PNP.NO | 55mm | Cable,2m,3-wire | |
| POH-M3010P2-DF3-230 | |
M30 | 10mm | Flush 齊平 | PNP.NC | 55mm | Cable,2m,3-wire | |
| PHH-M3015N1-DF3-230 | |
M30 | 15mm | Non-flush 非齊平 | NPN.NO | 55mm | Cable,2m,3-wire | |
| PHH-M3015N2-DF3-230 | |
M30 | 15mm | Non-flush 非齊平 | NPN.NC | 55mm | Cable,2m,3-wire | |
| PHH-M3015P1-DF3-230 | |
M30 | 15mm | Non-flush 非齊平 | PNP.NO | 55mm | Cable,2m,3-wire | |
| PHH-M3015P2-DF3-230 | |
M30 | 15mm | Non-flush 非齊平 | PNP.NC | 55mm | Cable,2m,3-wire |
